Kurth KB25 Track Mounted Rotary Drill Rig ($115,000 ex GST) (sale-ehub4450)For Sale$0.00Make: Kurth Model: KB25 Rotation Speed: 0-120 RPM Max. Torque: 5,000 Nm Stroke: 2,300 mm Max. Pullback Force: 48 kN Max. Feed Force: 32 kN Max. Casing Clamping Diameter: 273 mm Max. Casing Pullback Force: 150 kN Rotary Drive Travel Speed: 40m/min (max.) Rotary Drive Tilt Out Angle: 40 degrees from vertical - Set up for Shell & Auger - Drilling & Casing Clamp Range from 114 mm OD to 219 mm OD Drilling Capacity; Auger Drilling with Casings Ø 219/178 mm: 25-40 metres Hollow Stem Augers Ø 195/110 mm: 40 metres Direct Mud Rotary Drilling Ø 190 mm: 100 metres Down Hole Hammer Drilling Ø 150 mm: 100 metres Track Mounted Rotary Drill Rig Location: Western Australia Learn MoreMachine hours N/A KILOMETERS N/A YEAR N/A BRAND N/A
LOCATION Western Australia
MODEL KB25
-
VB10 Track Mounted Dual Rotary Drill Rig ($409,500 ex GST) (sale-ehub4427)For Sale$409,500.00Model: VB10 Engine: Deutz TCD2012L04 4 Cylinder Working Pressure: Max. 350 Bar Torque (Inside Rods): 3,700 / 7,400 Speed: 120 / 60 RPM Torque (Outside Rods): 12,000 / 24,000 Speed: 54 / 27 RPM Max. Breaking Torque: 46,000 Nm Drill Pole; Pole Profile: 300 x 200 x 8 mm Pole Height: 7,190 mm Stroke: 3,600 mm Hook Load / Pulling Force (Chain): 120 kN / 245 kN Max. Contact Pressure (Chain): 60 kN Travelling Speed: Up to 40 m/min Max. Rod Length: 2 m Track Mounted Dual Rotary Drill Rig Location: Western Australia Learn MoreMachine hours N/A KILOMETERS N/A YEAR N/A BRAND N/A
LOCATION Western Australia
MODEL VB10
-
2022 VersaDrill KmN1.4sm Track Mounted Core Drill Rig (POA) (sale-ehub4426)For Sale$0.00Make: VersaDrill Model: KmN1.4sm Year: 2022 Hours: 3,500 Depth Capacity: N Size @ 2,294 m (7,526 ft) Rotary Head Ratio: 1:2,33 Speed: 0 to 1,250 RPM Spindle Interior Dimension: 124 mm (4.9" Inches) Hydraulic Motor: 160 CC Variable Track Mounted Core Drill Rig Location: United States of America Learn MoreMachine hours 3,500
KILOMETERS N/A YEAR N/A BRAND Versadrill
LOCATION United States of America
MODEL KmN1.4sm
-
DS Curtis PMC 1204-606 + FLEXIT SmartTool Drillhole Survey System Wireline Winch & Tooling (Open to Offers) (sale-ehub4422)For Sale$0.00Make: DS Motor Controller; Make: Curtis PMC Model: 1204-606 Voltage: 12 Current: 275 Serial Number: 7005-719410 FLEXIT SmartTool Drillhole Survey System Wireline Winch & Tooling Location: Western Australia Learn MoreMachine hours N/A KILOMETERS N/A YEAR N/A BRAND N/A
LOCATION Western Australia
MODEL See Description
-
2x SRS ML Duo Track Mounted Multi Purpose Sonic Drill Rigs ($843,900 ex GST each) (sale-ehub4398)For Sale$843,900.00Make: SRS Model: ML Duo Year: 2022 Hours: 3,000 approx. - Remote Controlled Road/Casing Loader Tooling (for an additional $80,000 ex GST); - 3x GD 1.5 Metre Rods - 1.5 Metres of GD 5.5" Inch Casing - 1x Casing Shoe - 1x SW3 Barrel Quantity: 2 Track Mounted Multi Purpose Sonic Drill Rig *EXPORT ONLY – to be sold internationally outside of Australia* Location: Western Australia Learn MoreMachine hours 3,000 Approx.
KILOMETERS N/A YEAR N/A BRAND N/A
LOCATION Western Australia
MODEL SRS ML Duo
-
Austex X1550 Drill Rig ($580,500 ex GST) (sale-ehub4397)For Sale$580,500.00Make: Austex Model: X1550 Hours: 5,200 - Setup to be removed from truck - New Head fitted to rig in 2025 - MWL Rod Loader fitted in 2025 - Major Overhaul to meet MDG15 Compliance 2025 - Can Include the Rod Sloop (that matches truck) for the extra price @ $26,900 ex GST Drill Rig Location: New South Wales, Australia Learn MoreMachine hours 5,200
KILOMETERS N/A YEAR N/A BRAND AustEx
LOCATION New South Wales, Australia
MODEL X1550
-
2021 Sandvik DL411 Top Hammer Long Hole Drill Rig (POA) (sale-ehub4395)For Sale$0.00Make: Sandvik Model: DL411 Year: 2021 Hours: 56 (Drill Hours) Power: 140 kW / 50 Hz / 380 V Weight: 22.5 Tonne Top Hammer Long Hole Drill Rig Location: China Learn MoreMachine hours 56
KILOMETERS N/A YEAR 2021
BRAND Sandvik
LOCATION China
MODEL DL411
-
Revathi T650WM Drill Rig Mounted on 2005 Volvo FM9 Truck ($350,000 ex GST) (sale-ehub4383)For Sale$350,000.00Rig Make: Revathi Model: T650WM - Air Compressor - FMC Bean Pump - Duplex Mud Pump - Fire Extinguisher Truck Make: Volvo Model: FM9 Year: 2005 KM's: 362,000 Type: 10x4 Truck Mounted Drill Rig Location: Queensland, Australia Learn MoreMachine hours N/A KILOMETERS 362,000
YEAR 2005
BRAND N/A
LOCATION Queensland, Australia
MODEL T650WM
-
Sandvik DE712 Track Mounted Drill Rig (FOR HIRE/RENT - POA) (hire-ehub4379)For HireMake: Sandvik Model: DE712 Depth Capacity: 1,126 m (3,693 ft) N Size Feed Force: 5.5 Tonne (12,000 lbf) Pull Force: 9.3 Tonne (20,500 lbf) Feed Length (Stroke): 3.45 m Speed (Up & Down): 30m/min Track Mounted Drill Rig Location: Queensland, Australia Learn MoreMachine hours N/A KILOMETERS N/A YEAR N/A BRAND Sandvik
LOCATION Queensland, Australia
MODEL DE712
-
Edson 350 Drill Rig Mounted on 1975 Toyota 75 Series Landcruiser ($125,000 ex GST) (sale-ehub4359)For Sale$125,000.00Rig Make: Edson Model: 350 Hours: 4,500 Air Compressor: Compair/Broomwade (Plate No: C20450/206) - 25x Rods @ 2,050 mm long - 1x with Downhole 75 mm Hammer attached - 2x 75 mm Button Bits for Hammer and numerous Drag Bits included - 3x Bog Mats for Stabiliser Legs - 2-3x Rods have worn threads that would need re-machining/built up Vehicle Make: Toyota Model: 75 Series Landcruiser Year: 1975 Vehicle Mounted Drill Rig Location: Victoria, Australia Learn MoreMachine hours 4,500
KILOMETERS N/A YEAR 1975
BRAND Edson
LOCATION Victoria, Australia
MODEL 350
-
2x 2016 Epiroc Boomer 282S Underground Double Arm Drill Rigs (POA) (sale-ehub4357)For Sale$0.00Make: Epiroc Model: Boomer 282S Year: 2016 Hours; Unit 1: 2,654 / Arm 1: 1,614 / Arm 2: 1,872 Unit 2: 2,453 / Arm 1: 1,992 / Arm 2: 2,207 Quantity: 2 Underground Double Arm Drill Rig Location: Chile Learn MoreMachine hours See Description
KILOMETERS N/A YEAR 2016
BRAND Epiroc
LOCATION Chile
MODEL Boomer 282S
-
2017 Epiroc Rocket Boomer 282 Double Arm Drill Rig (POA) (sale-ehub4356)For Sale$0.00Make: Epiroc Model: Rocket Boomer 282 Year: 2017 Hours: 6,610 Percussion Hours: 3,009 / 2,987 Electric Hours: 3,601 / 4,113 Drill: COP 1838 HD+ - Double Arm - Fixed Beams of 16' Foot Drill Rig Location: Peru Learn MoreMachine hours 6,610
KILOMETERS N/A YEAR 2017
BRAND Epiroc
LOCATION Peru
MODEL Rocket Boomer 282
-
2017 Epiroc Boomer S1D Drill Rig (POA) (sale-ehub4355)For HireMake: Epiroc Model: Boomer S1D Year: 2017 Hours: 3,171 / 315 (Percussion Hours) Engine: Deutz B4L914 @ 72.4 KW Rock Drill: Sandvik HLX5 Transmission: Rexroth A4VG56 Feed Beam: Adapted with Feed Chain - Electric Motor and Compressor - Electrical Cabinet (A10) - Electrical Collector - Cooler - Hydraulic Control Block - ROPS Operator Cabin Drill Rig Location: Chile Learn MoreMachine hours 3,171
KILOMETERS N/A YEAR N/A BRAND Epiroc
LOCATION Chile
MODEL Boomer S1D
-
1992 Reichdrill T-100 Drill Rig Mounted on Custom Crane Carrier ($65,000 ex GST) (sale-ehub4350)For Sale$65,000.00Rig Make: Reichdrill Model: T-100 Year: 1992 Hours: 3,567 Engine: Cummins (700 HP) Pull Up: 50 Tonne Pull Down: 20 Tonne Capacity: 1,200 m - Hydraulic Pipe Handler attached to Mast - 2 Speed Head - 140 RPM Max. Rotation - 132,000 lb Torque - Manual Slips w/ Dies to suit 2 3/8" Inch, 2 7/8" Inch & 3 1/2" Inch Pipe - Has sat for 3 years, need some refurbishment - Heavy Duty, Deep Water Rig Carrier Make: Custom Miles: 17,064 Engine: Cummins Crane Carrier Mounted Drill Rig Location: Queensland, Australia Learn MoreMachine hours 3,567
KILOMETERS N/A YEAR 1992
BRAND Reichdrill
LOCATION Queensland, Australia
MODEL T-100
-
Drilling Consumables Package (Open to Offers) (sale-ehub4349)For Sale$0.00Includes; - 7x NMLC Bit and Reamers - 3x NMLC Bits - 2x NMLC TC Core Bit - 1x HMLC Used Bit and Reamer - 1x HMLC New S15 Core Bit - 1x HMLC New Reamer - 1x HMLC Used Core Bit - 1x Tri Cone 2 15/16" Inch - 1x Tri Cone 3 7/8" Inch - 1x HQ3 Bit Reamer Fordia S11/14 - 5x HQ3 Used IMP Bits - 2x HQ3 TC Core Bits - 1x PQ3 Near New IMP Core Bit - 1x C4 IMP Bit and Reamer - 1x NW IMP Shoe Bit - 1x NW TC Shoe Bit - 1x HQ Rod TC Shoe Bit - 2x NQ3 Near New IMP Core Bits - 3x NQ Reamers - 1x NQ Rod Reamer - 1x NQ New IMP Core Bit Hayden S14/15 - 1x HQ New Reamer - 1x HQ Near New Reamer - 1x New 3 7/8" Inch Drag Bit - 2x Near New 4 1/2" Inch Drag Bit - 1x NMLC New Hard Core S6 - 1x NMLC New Reamer - 1x NQ3 Hard Core S15 - 9x 2 Metre Used RC Rods - 1x Used 1.5 Metre RC Rod with Bit - 4x Worn Augers - 1x Used 4 1/2" Inch Bit - 1x New 4 1/2" Inch Bit - 1x 6 1/2" Inch Drag Bit - 1x 100 mm Tube Adapter - 1x 75 mm Tube Adapter - 2x 50 mm Tube Adapter Plus 50 mm Piston Sampler Drilling Consumables Package Location: Queensland, Australia Learn MoreMachine hours N/A KILOMETERS N/A YEAR N/A BRAND N/A
LOCATION Queensland, Australia
MODEL See Description
-
2016 Atlas Copco DM45 HP Track Mounted Drill Rig (POA) (sale-ehub4346)For Sale$0.00Make: Atlas Copco Model: DM45 HP Year: 2016 - Very Good Repair History Track Mounted Drill Rig Location: Canada Learn MoreMachine hours N/A KILOMETERS N/A YEAR 2016
BRAND Atlas Copco
LOCATION Canada
MODEL DM45 HP
-
2018 Exploration Drill Masters EDM 95K Track Mounted Drill Rig (POA) (sale-ehub4344)For Sale$0.00Make: Exploration Drill Masters EDM Model: 95K Year: 2018 Hours: 32,431 Drill Head Hours: 32,431 Compressor Hours: 32,431 Onboard Air Pack: Sullair 1,150 CFM / 500 PSI Air Compressor - Spare Parts available (can provide a detailed list with pricing) - EDM MK2 Core Rod Feeder (For additional $USD350,000) Track Mounted Drill Rig Location: United States of America Learn MoreMachine hours 32,431
KILOMETERS N/A YEAR 2018
BRAND EDM
LOCATION United States of America
MODEL 95K
-
2025 Geoprobe 7822DT Track Mounted Drill Rig (POA) (sale-ehub4343)For Sale$0.00Make: Geoprobe Model: 7822DT Year: 2025 Hours: 319 - Geoprobe GH63 Hammer - Tethered and Wireless Remote - 4 Speed Head (4,000 ft-lbf @ 750 RPM) - Dual Winch Kit - 3' Mast Extension - 7" Inch Breakout Kit - H Feed Control / CPT Valve Kit - 140 lbs Auto Drop Hammer - Anvil Hanger - ADH Drive Cap AWJ, Pin Down - 5' Extruder with Moyno 3L6 - Helper Side - 53" Inch Toolbox - Open Storage Box - Drop Rack System w/ Rod Rack - Yoke Vise & Mounting Bracket - High Speed Water Swivel w/ Float - Float Sub NWJ Pin Assembly Track Mounted Drill Rig Location: United States of America Learn MoreMachine hours 319
KILOMETERS N/A YEAR N/A BRAND Geoprobe Systems
LOCATION United States of America
MODEL 7822DT
-
2012 Schramm AD400AC Track Mounted Drill Rig (POA) (sale-ehub4342)For Sale$0.00Make: Schramm Model: AD400AC Year: 2012 Hours: 10,600 Mast Top Head Travel: 4.7 m Mast Slide (Dump): 2.38 m Pullback Capacity: 13,607 kg (30,000 lb) - Rod Loader with 120 Metre Capacity of 3.5" Inch x 3 Metre RC Rods (Rods Not Included) - FMC EO413 Water Injection Pump (82 LPM @ 48 Bar / Max Pressure: 103 Bar) - Rotary Head (0-146 RPM / 6,022 Nm (4,442 ft lb) - 800 Litre Fuel Tank - 1,000 Litre Water Tank Refurbishments; - All Hydraulic Pumps fully reconditioned (Only have less than 4,000 hours) - Compressor fully reconditioned (Less than 4,000 hours) - Complete Mast changed (Less than 4,000 hours) - Engine & Hydraulic Cooler (Less than 4,000 hours) - CAT 3406 Engine (10,600 hours) Fully Reconditioned & In stock, can arrange to fit to rig for extra - Sullair Air Compressor 20/12 H 1,150 CFM / 1,800 RPM to 1,350 CFM / 1,800 RPM (Max Discharge Pressure: 500 PSI @ 1,150 CFM & 350 PSI @ 1,350 CFM) - Fully Reconditioned (Little less than 8,000 hours) Track Mounted Drill Rig Location: New Caledonia Learn MoreMachine hours 10,600
KILOMETERS N/A YEAR 2012
BRAND Schramm
LOCATION New Caledonia
MODEL AD400AC
-
2x 2024 MI1 Auger / SPT Drill Rigs (POA) (sale-ehub4341)For Sale$0.00Model: MI1 Year: 2024 Hours: 0 (Never Used - In Storage) - Designed for Ute or Trailer Quantity: 2 Auger / SPT Drill Rig Location: Victoria, Australia Learn MoreMachine hours N/A KILOMETERS N/A YEAR N/A BRAND Home Made
LOCATION Victoria, Australia
MODEL MI1
